MANROLAND LITHOMAN 64 Rotary Offset Printing Press
Tip
lot no. 1
700,000 €
5 watchers
Log in to bid
€
Use bidding agent
+ auction fee & VAT
01/02/24 11:00
Closing time
700,000 €
Starting bid
Item details
- Name
- MANROLAND LITHOMAN 64 Rotary Offset Printing Press
- Item number
- 749816
- Manufacturer
- MANROLAND
- Model / Type
- LITHOMAN 64
- Year of manufacture
- 2001
- Item available from
- Immediately
- Item condition
- Location
-
Italy, region Torino
- Virtual 3D Tour: View this item on site
Costs and benefits
- 5 %
- Total Price
- plus VAT
- Shipping costs
- not included
- Delivery terms
- EXW, ex foundation, unpackaged
- Payment terms
- 100% payment prior to collection
Technical details
- Approx. Onsite Dimension. (l x w x h)
- unknown
- weight approx.
- 1 kg
Item description
PDF All the photos - Large file size, 100% verified
Cylinder diameter 1240 mm
Max. paper roll width 1905 mm
Speed approx 40.000 r/h
Machine revolutions approx. 1,875,129,000
AUROroll coil transport system
4-unit printing machine Black - Cyan - Magenta - Yellow
Paper rewetting unit
Folding overstructure
Exit on GAMMERLER KL 513/1 stacker and MOSCA double strapping machine
Palletising island with FANUC M-410 IB robotic arm
PECOM 2 Remote control Unit
Plate bender
Cylinder diameter 1240 mm
Max. paper roll width 1905 mm
Speed approx 40.000 r/h
Machine revolutions approx. 1,875,129,000
AUROroll coil transport system
- Max. paper reel width 1905 mm
- Paper Reel diameter 500 - 1270 mm
- Max. paper reel weight 3200 kg
- Paper weight 37 - 150 g/m3
- Speed 50 - 1020 m/min
- Reel core diameter 76 mm
- Margin +o- 20 mm
4-unit printing machine Black - Cyan - Magenta - Yellow
- Motorised circumferential, lateral and diagonal register adjustment
- Auxiliary motorisation for each printing unit
- Automatic PPL plate changer
- Film Inking
- Hydromix dampening device
- Dampening water circulation system with refrigeration and alcohol dosing
- Power 338 kW
- Natural Gas
- Heat output 2050 kW
- Max. air temperature 315 °C
- Minimum flow rate 11568 m3/h
- Max. solvent flow rate 32.13 g/s
- with 6 cooling cylinders
Paper rewetting unit
Folding overstructure
- WEKO silicone applier
- Cutting device with 2 blades
- Cylinder speed 40,000 rpm
- Paper speed 13.788 m/s
- Gluing device
- Cutting register
- 70° cone
- Fold: Delta / double parallel
- Transversal and longitudinal perforation
- 1x transversal fold with two cadenced exits
- 2x 3° fold with exit on conveyor belt
- With 2 GAMMERLER RS 134/530 trimming machines
- Power 7.5 kW each
Exit on GAMMERLER KL 513/1 stacker and MOSCA double strapping machine
Palletising island with FANUC M-410 IB robotic arm
PECOM 2 Remote control Unit
Plate bender
Automatic translation
Auction details
- Auction name
- Warehouse Liquidation of a Renowned Printing Company
- lot no.
- 1
- Documents
- Spec. Auction Terms
- Inspection
-
Monday, 29/01/2024, from 10:00 to 12:00
Viewing by appointment only!
Turin Area
Italy
